Plot survival of household members

Plot survival probabilities for each household members and for the entire household when at least one member is alive. The household joint survival probability is also approximated by a Gompertz model.

Usage

plot_survival(household, current_date = get_current_date())

Arguments

household

An R6 object of class Household.

current_date

A character. Current date in the format YYYY-MM-DD. By default, it is the output of get_current_date().

Value

A ggplot object.

Examples

hm1 <-
 HouseholdMember$new(
   name       = "member1",
   birth_date = "1955-01-01",
   mode       = 88,
   dispersion = 10.65
 )
hm2 <-
 HouseholdMember$new(
   name       = "member2",
   birth_date = "1965-01-01",
   mode       = 91,
   dispersion = 8.88
 )
hm3 <-
 HouseholdMember$new(
   name       = "member3",
   birth_date = "1975-01-01",
   mode       = 88,
   dispersion = 7.77
 )
household <- Household$new()
household$add_member(hm1)
household$add_member(hm2)
household$add_member(hm3)

plot_survival(
 household    = household,
 current_date = "2020-01-01"
)
