Plot life expectancy of household members

Probability of dying at a given age is plotted for each member of a household. Also for each member the life expectancy is shown as dashed vertical line.

Usage

plot_life_expectancy(household)

Arguments

household

An R6 object of class Household.

Value

A ggplot object.

Examples

hm1 <-
 HouseholdMember$new(
   name       = "member1",
   birth_date = "1955-01-01",
   mode       = 88,
   dispersion = 10.65
 )
hm2 <-
 HouseholdMember$new(
   name       = "member2",
   birth_date = "1965-01-01",
   mode       = 91,
   dispersion = 8.88
 )
household <- Household$new()
household$add_member(hm1)
household$add_member(hm2)

plot_life_expectancy(household = household)
